Elysion 6CT

Weatherproof - EN54-24

Click on the image to zoom

Download

Technical Specifications

Code:

47329 (Black) - 47329 (White)

Configuration:

2 way

Type:

Ceiling mounted speaker

Frequency response:

62 kHz - 20.000 Hz

Sensitivity (@1W/1m):

89.5dB

Input:

ABS / Steel

Power taps:

60 / 30 / 15

Low frequency woofer:

6.5''

High frequency:

0.75''

Net Dimension (WxHxD):

Ø325 x 201 mm / Ø12,8 x 7,9 inch

Net Weight:

4.5 Kg / 9,92 Lb

Recommended Amplifier:

120W

Rated Long Term Power (IEC):

60W

Rated Short Term Power IEC:

240W

Impedance:

16 Ohm

Maximum SPL cont/peak:

106.5 / 94.5dB

Datasheet

1.13 MB

User Manual

4.92 MB
