MIURA 8008I

DIGITAL AMPLIFIER

MIURA 8008I

Click on the image to zoom

Download Related Products

The MIURA 8008I is a high-power, 8-channel Class D amplifier designed for fixed installations requiring flexibility, precision, and reliable high-output performance. Delivering up to 8×1000W at 4Ω, or 4×2000W at 100V in bridge mode, it supports both low-impedance (4/8/16Ω) and high-impedance (70/100V) lines with full asymmetric power distribution. Integrated Dante audio streaming (4 channels) and TCP/IP control (AES70 compatible) via EtherCON ports allow seamless integration into networked systems through INFINITO software. The amplifier also features AES3 digital inputs with link, to ensure compatibility with professional-grade systems. A front OLED display with encoder ensures onboard setup, while Euroblock I/O, GPIO, and comprehensive protection features guarantee safe, long-term operation in demanding installation environments.

  • 8×1000W at 4Ω | 8×900W at 70V | 4×2000W BTL (100V or 8Ω)

  • Class D topology with ultra-low distortion

  • Full asymmetric loading with SE and BTL operation

  • TCP/IP control (AES70) via INFINITO software

  • 4-channel Dante audio receiver (24-bit, 48–96kHz)

  • AES3 digital audio input with link

  • OLED display with push encoder for local setup

  • Auto-Standby / Wake function

  • Universal SMPS with Power Factor Correction

  • Euroblock I/O and 8-channel GPIO

Technical Specifications

44014

20 - 20k (-0.5dB , 3dB below rated power)

Class D - PWM modulator with ultra low distortion

Short Circuit, DC, Undervoltage, Temperature, Overload

482 x 88 x 504 mm / 18.97 x 3.46 x 19.84 inch 2U Rack Mount

9 Kg / 19.84 Lb
