HIMAXX 40A

ACTIVE POINT SOURCE 12"

HIMAXX 40A

Click on the image to zoom

Himaxx 40A is an active 2-way bi-amplified speaker with high output and extended low frequency response. Designed for both portable sound reinforcement and fixed installations, it features a 12″ custom woofer and a 1″ B&C compression driver coupled to a 90°H x 60°V rotatable horn, delivering precise dispersion and intelligibility. The built-in bi-amp module provides 1000W RMS (LF) Class D and 250W RMS (HF) Class G amplification, enabling maximum SPLs up to 133 dB. The on-board DSP includes a 3-band EQ with panel controls for optimal response in various configurations and venues. Constructed in sturdy polypropylene with ergonomic side handles and M10 rigging points, the enclosure is equipped with a 35mm pole mount socket and rear slanted profile for floor monitoring use. The Himaxx 40A is an ideal solution for small mobile PA setups, side fill, or stage monitoring in live environments.

  • Configuration: 2-way active bass reflex design
  • Low Frequency Woofer: 12″ custom woofer / 2.5″ VC
  • High Frequency Driver: 1″ B&C compression driver / 1.4″ VC
  • Max. SPL: 133 dB
  • Material: Polypropylene

Technical Specifications

26937

2 way

1000 / 250W RMS

45Hz - 20kHz -6dB

12'' - 3'' coil

1'' - 1.7'' coil

127 / 133dB

90° x 60° H x V

22 kOhm

XLR / Jack RCA aux

5 m / 16.4 ft

407 x 675 x 370 mm / 16 x 25.3 x 14.5 inch

18.7 Kg / 41.2 lb

600 x 850 x 520 mm / 23.6 x 33.4 x 20.4 inch

21.5 Kg / 47.3 Lb

Accessories

FMS 220BKS

FMS 220BKS

MSA 220BKS

MSA 220BKS

V 29

V 29

MSA 300BK

MSA 300BK

BOX101

BOX101
