VENTIS 206A

ACTIVE POINT SOURCE 2x6"

VENTIS 206A

Click on the image to zoom

Ventis 206 is a 2 way, bass reflex passive point source crafted with a birch plywood cabinet, scratch resistant enclosure and internal bracing.

Recommended amplifier 400W RMS. Rotatable horns for optimal horizontal or vertical sound dispersion angle. The 70° H x 50° V coverage of this 2 woofers 6.5″ LF / 1″ HF point source delivers in the listening area up to 123/127 dB SPL. Frequency response from 75Hz to 20kHz. Built-in passive crossover with soft-trip protection for the LF woofer and HF driver. B&C compression drivers and FBT’s own custom, long excursion woofers. Flexible mounting hardware and different accessories for ease of installation. Equipped with 1.38″ pole mount socket. 45° sloped profile for unobtrusive placement on-stage as a monitor.

The integrated rear handle makes the Ventis 206 easy to carry and safe to install. In addition, Ventis 206 offers a mounting bracket (optional). Ventis 206 can be deployed as a front fill, an under-balcony fill, as a main providing pristine speech intelligibility or simply as the full-range companion of a subwoofer.

  • Configuration: 2 way
  • Low Frequency Woofer: 2 x 6.5” – 1.5” VC
  • High Frequency Driver: 1 x 1” – 1.4” VC
  • Recommended Amplifier: 400W RMS
  • Maximum SPL: 127dB
  • Material: Baltic birch plywood

Technical Specifications

40639

2 way

700 / 200W RMS

70Hz - 20KHz -6dB

2 x 6.5'' - 1.5'' coil

1'' - 1.4'' coil

124 / 131 dB

70° x 50° rotatable HxV

22 kOm

XLR with loop / RCA ST

5m / 16.4ft

190 x 560 x 260 mm / 7.48 x 22.04 x 10.23 inch

13.2 Kg / 29 lb

290 x 660 x 360 mm / 11.41 x 25.98 x 14.17 inch

15 Kg / 33 lb

Accessories

FMS 220BKS

FMS 220BKS

VN-C 206

VN-C 206

MSA 220BKS

MSA 220BKS

MSA 300BK

MSA 300BK
